Phoenix+ LED bar 20" with strobe and position light

€329.59 €263.67
€329.59 /piece €263.67 /piece
Retailer price €329.59 /piece Retailer price €263.67 /piece
In stock
100 % of 100

20” bar with built-in strobelight that is R65 approved
Selectable orange or xenon white position light
105W and E-marked

Phoenix+ 20" (522 mm)

Auxiliary light and warning light in one unit with this multifunctional Ledson bar! Now you no longer have to think about mounting several extra lights and a strobe / warning light, you save space and get a simplified installation.

The bar is available in three different sizes (20", 32" and 40") and therefore fits everything from transport vehicles to trucks and excavators - to meet your needs. All lengths are E-approved as auxiliary lights according to ECE R112 and have approved strobelight (ECE R65). They are also equipped with xenon white or yellow / orange position lights, which is optional to connect.

You get awesome strength in the high beam and a safer job on the road!




  • Combo Beam light image (wide and oblong)
  • E-marked ECE R112 (ref. 50) - Read more about UNECE regulations here
  • ECE R65 / R7 / R10 (EMC-rated)
  • Range: 459 m (1 lux)
  • Lumen: 8820 lm (theoretical), 3586 lm (actual)
  • Color temperature 5700K (cold white)
  • Strobelight: Orange (ECE R65)
  • Position light: Xenon white alt. yellow/orange

Technical data:

  • 105 W (21 x OSRAM CSHP LED)
  • IP69K: withstands hot water under pressure - Read more about IP rating here
  • Aluminum housing and unbreakable polycarbonate lens
  • 2-pin DT connector (included)
  • Voltage: 10-30V


Dimensions & weight (excl. Brackets):

  • Width: 522 mm
  • Height: 40 mm
  • Depth: 54 mm (excl. Bracket)
  • Weight: 1300 grams


Cable colors:

  • Green: Flash function
  • Gray: White position light
  • Yellow: Orange position light

The 2-pole DT-contact has +/- and fits bolt on against Ledson Connect

NOTE: The DT connector must not be cut as it entails an increased risk of moisture damage and the warranty then ceases to apply. DT connector (male) with joint included with the product.

Technical information
Manufacturer Ledson
Warranty 36 Months
Width 522 mm
Unit st
Light flux 8820 lumen (faktiska 3586)
Cable length 1 meter
Depth 54 mm (exkl. fäste)
Height 40 mm
